ZONESUN ZS-CFC5 Semi-Automatic Beer Bottle Vacuum Filling & Capping Machine
ZONESUN ZS-CFC5 Semi-Automatic Beer Bottle Vacuum Filling & Capping Machine
Couldn't load pickup availability
Description
The ZONESUN ZS-CFC5 is a semi-automatic beer bottle filling and capping machine designed for small to medium-scale breweries. Running at 200–240 bottles per hour, it integrates filling and capping functions with a vacuum system to ensure stable performance and reliable sealing. Built with high-quality stainless steel, the machine is durable, safe, and easy to operate. Its modular design includes filling nozzles, capping head assembly, storage tanks, and a pressure controller, making it suitable for various bottle types and ensuring consistent production efficiency.
Parameter
| Parameter | ZS-CFC5 |
|---|---|
| Model | ZS-CFC5 |
| Power Supply | 220V, 50Hz, Single Phase |
| Production Speed | 200–240 bottles/hour |
| Working Table Surface Size | 1500 × 270 mm |
| Working Table Surface Height | 850 mm |
| Overall Machine Size (L×W×H) | 1500 × 800 × 2100 mm |
| Maximum Stroke of Cylinder Piston | 350 mm |
| Net Weight | 280 kg |
| Filling Type | Positive Pressure Filling |
Applications
- Craft Beer Bottling: Engineered specifically for craft beer. Equipped with a vacuum function, it efficiently evacuates air from the bottle before filling, minimizing oxygen pickup to preserve the beer's original flavor and extend shelf life.
- Carbonated Beverage Filling: In addition to beer, it is widely used for filling soda water, carbonated juices, cider, and other sparkling beverages.
- Micro-Scale Production: Ideal for start-up breweries, microbreweries, brewpubs, laboratory sampling, or limited-edition runs.
- Glass Bottles: Universally compatible with standard 330ml, 500ml, and varying shapes of amber, green, or clear glass beer bottles.
- Crown Cap Sealing: Features a heavy-duty capping head designed precisely for standard metal crown caps, ensuring a tight, leak-proof seal that locks in carbonation and pressure.
Intuitive Control Panel
Efficiently manage filling and capping operations with intuitive start, stop, and emergency controls designed for maximum safety and productivity.
FILLING NOZZLES
Dispenses beer into bottles with precise volume control, minimizing foam, spillage, and contamination.
CAPPING HEAD
Automatically places and seals caps onto bottles with consistent downward force, ensuring leak-proof and secure packaging.
STORAGE TANKS
Stores beer before filling, maintains stable liquid supply, and supports pressure control for consistent dispensing.
PRESSURE CONTROLLER
Monitors and regulates internal pressure to ensure stable liquid flow and safe, consistent filling performance.
