Zonesun ZS-BFS1 Blow Filling and Sealing Machine
Zonesun ZS-BFS1 Blow Filling and Sealing Machine
Precio habitual
$750,000.00 USD
Precio habitual
$800,000.00 USD
Precio de oferta
$750,000.00 USD
Precio unitario
por
Los gastos de envío se calculan en la pantalla de pago.
No se pudo cargar la disponibilidad de retiro
The Zonesun ZS‑BFS1 Blow Fill Seal Machine is a cutting‑edge solution for aseptic primary packaging of liquids. Combining container forming, filling, and sealing in one seamless process, it ensures sterile, precise, and efficient production. Designed for pharmaceutical applications, it delivers consistent quality, reduces contamination risks, and supports a wide range of liquid products with exceptional reliability.
| Model | ZS‑BFS1 |
|---|---|
| Dimensions (L × W × H) | 4980 × 2660 × 2800 mm |
| Weight | 9 t |
| Deflasher | Outside |
| Power Source | 3‑phase, AC 380 V, 50 Hz |
| Installed Power | 75 kW |
| Power Rating | 45 kW |
| Machine Structure | Dark‑side / white‑side separation |
| Packing Materials | PP / PE / PET |
| Specification | 0.2 – 5 ml; 5‑10‑20 ml |
| Capacity (Bottles/hour) | 0.2‑5 ml: 900 pcs; 5‑10‑20 ml: 6000 pcs |
| Filling Accuracy | ± 1.5 % (pure water, 5 ml) |
| Manufacturing Standard | cGMP |
| Electrical Standard | IEC 60204‑1 (safety of machinery electrical equipment); GB/T 4728 (graphical symbols for electrical diagrams) |
| Compressed Air | Oil‑free, water‑free, 8 bar, 30 NL/min |
| Cooling Water | Pure water, 12 °C, 4 bar, 3 m³/h |
| Pure Steam | 125 °C, 2 bar, 40 kg/h |
