ZONESUN ZS-MD60 Industrial X-Ray Inspection System for Food & Pharma Packaging
ZONESUN ZS-MD60 Industrial X-Ray Inspection System for Food & Pharma Packaging
No se pudo cargar la disponibilidad de retiro
Description
The ZONESUN ZS-MD60 is a high-precision industrial X-ray inspection system designed for online detection and automatic rejection of foreign object contaminants in packaged products. Using an 80 kV X-ray source (max 210 W) and advanced image analysis running on a Linux-based operating system, it reliably detects metal (ball ≥0.3 mm, wire ≥0.2×2 mm), glass, ceramic, stone, and dense contaminants in composite, foil, and multi-layer packaging that defeats conventional metal detectors. With a 500×300 mm inspection tunnel, up to 20 kg product capacity, conveyor speeds of 5–60 m/min, and a high-efficiency pneumatic automatic rejection device, the ZS-MD60 ensures food safety and quality control on high-speed production lines. The full mirror 304 stainless steel body and IP66-rated conveyor meet food-grade hygiene and washdown requirements.
Parameters
| Parameter | Specification |
|---|---|
| Model | ZS-MD60 |
| X-Ray Source | 80 kV, max power 210 W |
| Operating System | Linux (Kernel 4.10) |
| Conveyor Speed | 5–60 m/min |
| Max Product Weight | 20 kg |
| Inspection Tunnel (W × H) | Max 500 mm × Max 300 mm |
| Power Supply | AC 220V, 50–60 Hz |
| Waterproof Rating | Conveyor IP66 / Other components IP40 |
| Body Material | Full mirror 304 stainless steel |
| Operating Temperature | 0–45°C, Humidity 30–85% (non-condensing) |
| Detection Accuracy — Metal Ball | ≥ 0.3 mm |
| Detection Accuracy — Metal Wire | ≥ 0.2 × 2 mm |
| Detection Accuracy — Ceramic / Glass Ball | ≥ 1.0 mm |
- Packaged Foods & Snacks: Ideal for inline scanning of potato chips, biscuits, dried fruits, nuts, candies, and packaged bakery items. Accurately identifies glass shards, stones, and micro-metal wires in foil-sealed pouches or metallized bags without false triggers caused by salt or moisture content.
- Dairy, Meats & Ready-to-Eat Meals: Perfect for vacuum-packed cheese, butter, sausages, frozen poultry, and prepared meals. Penetrates dense organic material to detect residual calcified bone fragments, stainless steel debris, and hard plastic contaminants before product release.
- Pharmaceuticals & Medical Products: Designed for strict quality assurance in blister packs, bottled tablets, powder sachets, and medical dressings. Detects broken glass from vials, metal fragments, or missing/incomplete doses inside secondary packaging.
- Condiments, Sauces & Canned Goods: Scans bottled sauces, spice powders, and boxed liquids. Inspects through thick plastic containers and foil lids to ensure no foreign objects compromise product purity or brand safety.
- Non-Food & Consumer Goods: Suitable for non-destructive testing (NDT) of cosmetics, personal care products, rubber parts, and small hardware components to verify internal integrity and ensure zero defective units reach customers.
CONTROL PANEL
Features a high-definition control panel to automatically calibrate product density profiles and monitor real-time X-ray inspection images.
INSPECTION CHAMBER
Equipped with an industrial-grade 80kV X-ray source and stable Linux OS to instantly pierce composite packaging, delivering high-speed, error-free real-time image analysis.
MATERIAL CONVEYING
Features a high-capacity 500x300mm tunnel and a robust structure supporting up to 20kg to perfectly accommodate online detection for various boxes, large bags, and cartons.
REJECTION DEVICE
Utilizes a high-efficiency pneumatic pusher mechanism to instantly and precisely eliminate defective products off the line without disrupting standard workflow.
PHOTOELECTRIC SENSOR
Triggers the X-ray source within milliseconds via photoelectric sensors to pinpoint contaminants, providing flawlessly synchronized timing for precise rejection.
